The CCR1009 is a powerful Ethernet router based on the cutting edge TILERA 9 core CPU.
CCR1009-8G-1S-1S+ comes with 2GB of RAM, eight Gigabit Ethernet ports (Ether1-4 are in a Switch group), one SFP port and one SFP+ port with 10G support (SFP module not included).
CCR1009-8G-1S-1S+ model have dual power supplies built in for redundancy (if one power line fails, the other one will take over automatically).
Also, CCR1009-8G-1S-1S+ supports a Smart card, to store your private key for use in all features that support Certificate based authentication.
SFP+ port supports SFP (1.25G) modules as well.
|CPU nominal frequency||1.2 GHz|
|CPU core count||9|
|Size of RAM||2 GB|
|10/100 Ethernet ports||0|
|10/100/1000 Ethernet ports||8|
|Number of USB ports||1|
|Supported input voltage||14 V – 57 V|
|CPU temperature monitor||Yes|
|PCB temperature monitor||Yes|
|Operating temperature range||-20C .. +60C|
|Antenna gain DBI||No|
|Max Power consumption||35W|
|USB slot type||microUSB type AB|
|Number of chains||0|
|Serial port||RS232 + Header|
