5 GHz PtMP LTU Long-Range Client, functions in a PtMP environment with the LTU-Rocket as the BaseStation.
Incorporating innovative industrial design with advanced technology, the LTU LR is a Point-to-MultiPoint (PtMP) 5 GHz Radio with an integrated antenna designed for use as a PtMP CPE. LTU technology that breaks through the limitations of 802.11 Wi-Fi technology and supports 1024QAM for high performance and flexible bandwidth (10/20/30/40/50 MHz).
|Dimensions||512.5 x 385.75 x 258.3 mm
(20.18 x 15.19 x 10.17″)
|1.360 kg (2.998 lb)
1.735 kg (3.825 lb)
|Networking Interface||(1) 10/100/1000 Ethernet Port|
|Enclosure||Outdoor UV Stabilized Plastic|
|Max. Power Consumption||8.5W|
|Power Supply||24V, 0.5A Gigabit PoE Adapter (Included)|
|Power Method||24V Passive PoE (Pairs 4, 5+; 7, 😎|
|Voltage Range||22 – 26V|
|Max. Conducted TX Power||22 dBm (per Chain)|
|Mounting||Pole-Mount (Kit Included)|
|Wind Loading||550 N @ 200 km/h
(123.6 lbf @ 125 mph)
|Wind Survivability||200 km/h
|ESD/EMP Protection||± 24kV Contact/Air|
|Operating Temperature||-40 to 60° C (-40 to 140° F)|
|Operating Humidity||5 to 95% Noncondensing|
|Certifications||CE, FCC, IC|
