ePMP™ Force 190

Wireless service providers and enterprises around the globe are
challenged to deliver reliable connectivity in overcrowded RF
environment. As spectrum increasingly becomes a scarce commodity,
finding the right broadband connectivity solution is vital for all low
and high density types of deployments.


• Cambium Networks’ ePMP Force 190 will lower the logistical cost of ownership
by reducing shipping costs with its highly compact packaging.
• The ePMP Force 190 is designed to operate in high interference environments
and provides throughput of up to 200Mbps with bi-directional traffic of real user data.
• Configurable Modes of operation ensure robust adaptivity to both symmetrical and
asymmetrical traffic while providing high performance and round-trip latency as low as 2 – 3 ms.
• QoS management offers an outstanding quality for triple play services – VoIP, video and data and provides three levels of traffic priority.
• Long deployment range is enabled by a high gain antenna combined with 27dBm of transmit power.
• This platform is for the user base that wants a smaller on premises footprint while enabling high gain.
• Install is a breeze with the easy to install mount, capable of pole and wall mounting.


Product Description


Channel Spacing Configurable on 5 MHz increments
Frequency Range 4910 – 5970 MHz, 4.9 only for ROW
Channel Width 5 | 10 | 20 | 40 MHz


MAC (Media Access Control) Layer Cambium Proprietary
Physical Layer 2×2 MIMO/OFDM
Ethernet Interface 10/100 BaseT, Compatible with Cambium PoE & Standard PoE pinouts
Protocols Used IPv4, IPv6, UDP, TCP, IP, ICMP, SNMPv2c, HTTPs, STP, SSH, IGMP Snooping
Network Management HTTPs, SNMPv2c, SSH
VLAN 802.1Q with 802.1p priority


Nominal Receive Sensitivity (w/FEC)
@20 MHz Channel
MCS0 = -92 dBm to MCS15 = -68 dBm (per branch)
Nominal Receive Sensitivity (w/FEC)
@40 MHz Channel
MCS0 = -89 dBm to MCS15 = -65 dBm (per branch)
Modulation Levels (Adaptive) MCS0 (BPSK) to MCS15 (64QAM 5/6)
Quality of Service Three level priority (Voice, High, Low) with packet classification by DSCP, COS, VLAN ID, IP & MAC Address, Broadcast, Multicast and Station Priority
Transmit Power Range -15 to +27 dBm (combined, to regional EIRP limit) (1 dB interval)
Antenna Gain 22dBi


Surge Suppression 1 Joule Integrated
Environmental IP55
Temperature -30°C to +50°C (-22°F to +122°F)
Weight 1.0 kg (2.2 lbs)
Wind Survival 125 km/hour (78 mi/hour)
Dimensions (Dia x Depth) 35 cm x 28 cm (13.5 in x 11.2 in)
Pole Diameter Range 3.8 cm – 6.4 cm (1.5 in – 2.5 in)
Power Consumption 8 W Maximum, 5 W Typical
Input Voltage 12 to 30 V


Encryption 128-bit AES (CCMP mode)


Industry Canada Cert 109W-0031
CE 5 GHz EN 302 502 v1.2.1
5 GHz: EN 301 893 v1.7.1
