DS-2CD1321-I

2.0 MP CMOS Network Dome Camera



    • 1/2.8″ progressive scan CMOS
    • Up to 2.0 megapixel
    • 2.8 mm/4 mm/6 mm fixed focal lens
    • Up to 30 m IR range
    • Dual stream
    • Digital WDR (Wide Dynamic Range)
    • 3D DNR (Digital Noise Reduction)
    • PoE (Power over Ethernet)
    • IP67
    • Mobile monitoring via Hik-Connect

DOWNLOAD:





Product Description



Camera

Image Sensor: 1/2.8″ Progressive Scan CMOS
Min. Illumination: 0.01Lux @(F1.2,AGC ON) ,0 Lux with IR
Shutter time: 1/3 s to 1/100,000 s
Slow shutter: support
Lens: 2.8 mm @F2.0, horizontal field of view 95°, 4 mm @F2.0, horizontal field of view 83.6°
6 mm @F2.0, horizontal field of view 55°
Lens Mount: M12
Adjustment Range: Pan: 0° to 360°, tilt: 0° to 75°, rotation: 0° to 360°
Day& Night: IR cut filter with auto switch
Wide Dynamic Range: Digital WDR
Digital noise reduction: 3D DNR


Compression Standard

Video Compression: H.264+/H.264/MJPEG
H.264 code profile: Baseline Profile/Main Profile
Video bit rate: 32Kbps~8Mbps
Dual Stream: Yes



Max. Image Resolution: 1920 x 1080
Frame Rate: 50Hz: 25fps @(1920 × 1080, 1280 × 960, 1280 × 720)
60Hz: 30fps @(1920 × 1080, 1280 × 960, 1280 × 720)
Sub Stream: 50Hz: 25fps @(704 × 576, 640 × 480, 352 × 288, 320 × 240)
60Hz: 30fps @(704 × 480, 640 × 480, 352 × 240, 320 × 240)
Image Settings: Brightness, saturation, contrast, sharpness are adjustable via web browser or client software
BLC: Yes, zone configurable
ROI: support 1 fixed region)
Day/Night Switch: Support auto, scheduled


Network

General Function: Anti-flicker, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
Network Storage: NAS (Support NFS,SMB/CIFS)
Alarm Trigger: Motion detection, video tampering alarm, network disconnected, IP address conflict, illegal login, HDD full, HDD error
Protocols: TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
System Compatibility: ONVIF (Profile S, Profile G), ISAPI


Interface

Communication Interface: 1 RJ45 10M/100M self-adaptive Ethernet port


General

Operation Condition: -30 °C to 60 °C (-22 °F to 140 °F), humidity: 95% or less (non-condensing)
Power Supply: 12 VDC ± 25%, PoE (802.3af Class3)
Power Consumption: Max. 4 W/6 W (PoE)
Weather Proof: IP67
IR Range: Up to 30m
Dimensions: Φ 85.5 mm × 70 mm (3.38″ × 2.76″)
Weight: 350 g (0.77 lb.)
