CCR2004-1G-12S+2XS

ROSE Data server (RDS)

RDS is a high-performance, all-in-one storage, 100G networking, and container platform designed for enterprise environments. Featuring 20 U.2 NVMe storage slots and a special RouterOS Edition for Storage & Compute (ROSE).



The Rose Data Server (RDS2216) is a high-performance, all-in-one storage, networking, and container platform designed for enterprise environments. It offers secure and scalable infrastructure, giving you full control over your data without relying on third-party cloud providers. With advanced security features and flexible deployment options, RDS2216 ensures your business stays protected and future-proof.

Specifications

Details
Product codeCCR2004-1G-12S+2XS
ArchitectureARM 64bit
CPUAL32400
CPU core count4
CPU nominal frequency1700 MHz
Dimensions443 x 224 x 44 mm
RouterOS license6
Operating System RouterOS v7
Size of RAM4 GB
Storage size128 MB
Storage typeNAND
MTBFApproximately 200'000 hours at 25C
Tested ambient temperature-20°C to 60°C
IPsec hardware accelerationYes
Suggested price$595.00

Powering

Details
Number of AC inputs2
AC input range100-240
Max power consumption60 W
Max power consumption without attachments31 W
Cooling type2 fans

Ethernet

Details
10/100/1000 Ethernet ports1

Fiber

Details
SFP+ ports12
Number of 25G SFP28 ports2

Peripherals

Details
Serial console portRJ45

Other

Details
CPU temperature monitorYes
PCB temperature monitorYes
Voltage MonitorYes

Certification & Approvals

Details
CertificationCE, EAC, ROHS
IP20

Included parts

BrochureOpen
Quick GuideOpen
User ManualOpen
RouterOS current releaseDownload
Block DiagramOpen
SFP compatibility listOpen
RouterOS software manualOpen
Declaration of conformityOpen (CE)

Download: Full CE declaration (PDF)
