AF-5G34-S45

AF-5G34-S45

5 GHz, 34 dBi antenna ideal for long range Point-to-Point (PtP) links.
Technical
AF-5G34-S45
Dimensions1050 x 1050 x 421 mm (41.34 x 41.34 x 16.57")
WeightWith Mount: 13.5 kg (29.76 lb)
Frequency5.1 - 5.8 GHz
Gain34 dBi
Max. VSWR1.4:1
Wind Survivability200 km/h (125 mph)
Wind Loading1,779 N @ 200 km/h (400 lb @ 125 mph)
PolarizationDual Linear
F/B Ratio42 dB
ETSI SpecificationEN 302 326 DN2
MountingUniversal Pole Mount, airFiber Radio Bracket, and Weatherproof RF Jumpers Included
NDAA CompliantYes
