RB2011iL-IN

The RB2011 is a low cost multi port device series. Designed for indoor use, and available in many different cases, with a multitude of options.
The RB2011iL-IN is the most basic model, with five Gigabit ethernet ports, five Fast ethernet ports, power jack and PoE support.
It’s powered by the new Atheros next generation 600MHz 74K MIPS network processor and has 64MB of RAM and a Level4 RouterOS license.
There is PoE output function for port #10 – it can power other PoE capable devices with the same voltage as applied to the unit. Maximum load on the port is 500mA.
RouterBOARD 2011iL-IN comes with desktop enclosure and power supply.
Wall mount kit for network closet is available for purchase as an optional accessory.



Categories: ,

Product Description

Product code RB2011iL-IN
CPU nominal frequency 600 MHz
Architecture MIPS-BE
CPU core count 1
Size of RAM 64 MB
Power Jack 1
Dimensions 214x86mm
Operating System RouterOS
Storage type NAND
Storage size 128 MB
10/100 Ethernet ports 5
CPU AR9344
Max Power consumption 6W
Supported input voltage 8 V – 30 V
PoE out Yes
PoE in Yes
10/100/1000 Ethernet ports 5
Tested ambient temperature -35C to +65C
License level 4
