DS7324HGI

DS-7324HGHI-SH

DVR

FEATURES:
  • H.264 & Dual-stream video compression
  • Support HD-TVI/analog/IP camera triple hybrid
  • Support both HD-TVI and analog cameras with adaptive access
  • Full channel@720P resolution real-time recording
  • HDMI and VGA output at up to 1920×1080P resolution
  • Long transmission distance over coax cable
  • Support up to 24/32-ch synchronous playback at 1080P resolution
DOWNLOAD:

brochuredn

Product Description

SPECIFICATIONS:

Video/Audio Input
Audio Input: | 4-ch
Video Compression: | H.264
Analog and HD-TVI video input: | 24-ch, BNC interface (1.0Vp-p, 75 Ω)
Supported camera types: | 720P/25, 720P/30, 720P/50, 720P/60, 1080P/25, 1080P/30, CVBS
IP Video Input: | 8-ch (up to 32-ch) Up to 2MP resolution
Video Input Interface: | BNC (1.0 Vp-p, 75Ω)
Audio Compression: | G.711u
Audio Input Interface: | RCA (2.0 Vp-p, 1 kΩ)
Two-way Audio: | 1-ch RCA(2.0Vp-p, 1kΩ)
Video/Audio Output
HDMI/VGA Output: | 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz
Recording resolution: | Main stream: 1080P (non-real-time) / 720P / WD1/ VGA / 4CIF / CIF;Sub-stream: WD1(non-real-time) / 4CIF(non-real-time) / CIF / QCIF / QVGA
Frame Rate: | Main stream: 1/16 fps ~ Real time frame rate
Sub-stream: 1/16 fps ~ Real time frame rate
Video Bit Rate: | 32 Kbps-6 Mbps
Stream Type: | Video/Video&Audio
Audio Output: | 1-ch RCA(Linear, 1kΩ)
Audio Bit Rate: | 64kbps
Dual Stream: | Support
Playback Resolution: | 1080P / 720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF
Synchronous Playback: | 24-ch
Network management
Remote connections: | 128
Network protocols: | TCP/IP, PPPoE, DHCP, EZVIZ Cloud P2P, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI,
UPnP™, HTTPS
Hard Disk Driver
Interface Type: | 4 SATA interfaces for 4 HDDs; 1 eSATA interface
Capacity: | Up to 6 TB capacity for each disk
External Interface
Network Interface: | 1; 10M / 100M / 1000M self-adaptive Ethernet interface
USB Interface: | 3 USB2.0 interfaces
Serial Interface: | 1RS-485 interface, 1 RS-232 interface, 1 RS-485 keyboard interface
Alarm Input: | 16-ch
Alarm Output: | 4-ch
General
Power Supply: | 100 ~ 240VAC, 47 ~ 63HZ
Consumption: | ≤ 55W
Working Temperature: | -10 ºC ~+55 ºC (14 ºF ~ 131 ºF)
Working Humidity: | 10% ~ 90%
Chassis: | 19-inch rack-mounted 1.5U chassis
Dimensions: | 445 × 390 × 70 mm (17.5 × 15.3 × 2.7 inch)
Weight: | ≤5Kg (11.0lb)
